基本参数 Basic Parameters | 尺寸（mm） | 1460×780×1200mm |
重量（weight） | 880 KG | |
最小转弯半径Minimum turning radius | 1.7 m | |
整车防护等级Vehicle protection level | IP54 | |
储能系统 ESS | 储能电池容量 | 70 KWh |
储能电池类型 | 磷酸铁锂 LFP | |
防护等级Protection level | IP67 | |
储能电池包热管理Thermal management of energy storage battery pack | 液冷 / 液热 Liquid cooling/liquid heating | |
充电系统charging system | 直流输出电压范围 | 200-1000 V DC |
充电枪线 最大输出电流 Maximum output current | 250 A | |
持续放电功率 continuous discharge | 80 KW | |
回充补能功率 Recharge and recharge power | 70 KW | |
充电枪线热管理Thermal management of charging gun cable | 液冷 liquid cooling | |
充电枪线尺寸Charging gun cable size | L: 6m , D:26.5 mm | |
充电枪数number of charging guns | 单枪 single | |
充电枪接口charging gun interface | 国标 GB/T 直流充电枪 / CCS2 | |
回充补能接口Recharge and recharge interface | 国标 GB/T 直流快充座 / CCS2 | |
驱动系统 drive system | 驱动类型 Drive Type | 前转后驱 FR |
刹车系统 brake system | 碟刹 disc brake | |
最大行驶速度 speed | 1.8 m/s（6.5km/h） | |
最大爬坡坡度 slope | 20% | |
驾驶方式 | 站立驾驶式 | |
用户界面 UI | 人机界面 HMI | 7" 显示屏，状态指示灯 7 "display screen, status indicator light |
灯光 light | 频闪、前照、转向 Strobe, front headlight, steering | |
急停开关Emergency stop switch | √ | |
电源开关（高压）Power switch (high voltage) | √ | |
电源开关（底盘）Power switch (chassis) | NFC | |
安全特性security features | 过 \ 欠压保护、短路保护、过流保护、过载保护、高温保护、绝缘监测、过压等级（三级）Overvoltage/undervoltage protection, short circuit protection, overcurrent protection, overload protection, high temperature protection, insulation monitoring, overvoltage level (level 3) | |
通信方式communication method | 4G | √ |
通信协议communication protocol | √ | |
充电运营管理云平台Charging operation management cloud platform | √ | |
工作环境working environment | 工作温度Operating Temperature | -20° C ~+55° C |
工作湿度Operating Humidity | 5% ～ 95% 无凝露 no condensation |
